How to Bending Straight Bar by Rebar Double Bender

/0 Comments/in /by

How to Bending Straight Bar by Rebar Double Bender

When it comes to concrete construction, bending reinforcing bars can use different rebar machines. One of the most effective tools for this task is the rebar double bender, also known as a double bar bender or rebar double bending machine. This specialized machine allows users to bend two rebars simultaneously, dramatically improving productivity and consistency on the job site. In this article, we will explore how to bending straight bar by rebar double bender, highlighting key features, step-by-step procedures, and best practices to ensure accurate and safe bending.

rebar double bender

itech Best selling CNC high quality automatic stirrup bending machine / CNC stirrup bender machine widely use in reinforcement steel wire bar cut and bend factory. Itech as professional reinforcing steel machine supplier. Itech  have a series of steel rebar bender machine,like  CNC 16mm Stirrup Bending machine,CNC 20mm stirrup bar bending machine , 14mm stirrup wire bending machine and bar shape machine ,automatic rebar pile cage welding machine,cnc automatic pile cage making machine , automatic truss lattice girder welding machine and many kinds of rebar machine. To solve the gap on the stirrups ,Itech stirrup bending machine adopt advanced anti twist feeding system to avoid twist of steel, make stirrup more quick and standard.Shape and bend stirrups effortlessly with our cutting-edge bending machine.

What is a Rebar Double Bender?

A double bar bender is a metal fabrication tool designed specifically for bending reinforcing steel bars used in concrete structures. Unlike single bar benders, this machine can bend different pieces rebars of  the same size and diameter at once, making it ideal for large-scale construction projects.

Key Benefits:

High Efficiency: Bends two bars simultaneously, reducing bending time.

Consistent Bends: Adjustable bending angles ensure uniformity.

Labor Savings: Minimizes manual effort and labor costs.

Versatility: Available in manual and hydraulic models to suit different project needs.

For example, hydraulic double benders offer powerful bending capabilities for high-volume work, while manual double benders are portable and suitable for smaller jobs.

Step-by-Step Guide: How to Bending Straight Bar by Rebar Double Bending machine

  1. Preparation and Safety

Before operating the rebar double bender:

Wear appropriate personal protective equipment (PPE), including gloves, safety goggles, and sturdy footwear.

Inspect the machine for any damage or defects.

Ensure the workspace is clean and free of obstructions.

  1. Select the Correct Bending Dies

Choose bending rollers or dies that match the diameter of your rebars.

Attach them securely to the machine according to the manufacturer’s instructions.

  1. Measure and Mark the Rebar

Accurately measure the length and mark the bending points on each bar using chalk or a permanent marker.

Consider the bend allowance, which accounts for material deformation during bending.

  1. Load the Rebars into the Machine

Place two rebars of the same size into the feeding slots of the double bender.

Align the marked bend points with the machine’s bending pins or rollers.

  1. Set the Bending Angle

Adjust the bending angle on the machine’s control panel or manual setting knob.

Common bending angles include 90° for hooks and stirrups or 135° for seismic ties.

  1. Execute the Bending Operation

For hydraulic models, activate the bending cycle using foot pedals or control switches.

For manual models, apply steady force using levers or cranks.

Ensure the bars bend smoothly without twisting or slipping.

  1. Inspect the Finished Bend

Use a protractor or angle gauge to verify the bend angle matches specifications.

Check for any signs of cracking or deformation, which may compromise strength.



Tips for Optimal Use of a Rebar Double Bender

Start with a Single Bar: If new to the machine, practice bending one bar at a time before progressing to double bending.

Maintain the Machine: Regularly lubricate moving parts and check hydraulic fluid levels (for hydraulic benders) to ensure smooth operation.

Avoid Overloading: Do not exceed the machine’s rated capacity to prevent damage or injury.

Use Proper Technique: Always position your hands and body safely to avoid accidents during bending.



Why Use a Double Bar Bender?

According to industry sources like itech China, double bar benders significantly increase bending speed and accuracy, making them indispensable for professional construction projects. Their ability to produce consistent, uniform bends reduces material waste and ensures compliance with engineering standards.



Conclusion

Mastering how to bending straight bar by rebar double bender is essential for anyone involved in concrete reinforcement work. This tool not only boosts productivity by bending two bars simultaneously but also guarantees precision and uniformity critical for structural safety. By following the steps outlined above and adhering to safety protocols, you can maximize the efficiency and quality of your rebar cut and bend fabrication.

Ready to enhance your construction workflow? Explore reliable double bar benders today and experience faster, safer, and more consistent rebar bending.

cage making machine

How Pile Cage Welding Machine work and rebar cage making machine workflow

/0 Comments/in /by

How Pile Cage Welding Machine work and rebar cage making machine workflow

cage making machine

A pile cage welding machine, also known as a rebar cage making machine, is a specialized piece of equipment used to automate the fabrication of steel reinforcement cages for deep foundations like piles. These cages are critical for providing tensile strength and structural integrity to concrete piles in major construction projects such as bridges and high-rise buildings. While methods like site-fixing with tying wire and manual welding are still used, modern machines offer superior speed, precision, and consistency. The operation of a typical CNC or semi-automatic pile cage machine is a multi-stage process that can be broken down into several key steps

itech Best selling CNC high quality automatic stirrup bending machine / CNC stirrup bender machine widely use in reinforcement steel wire bar cut and bend factory. Itech as professional reinforcing steel machine supplier. Itech  have a series of steel rebar bender machine,like  CNC 16mm Stirrup Bending machine,CNC 20mm stirrup bar bending machine , 14mm stirrup wire bending machine and bar shape machine ,automatic rebar pile cage welding machine,cnc automatic pile cage making machine , automatic truss lattice girder welding machine and many kinds of rebar machine. To solve the gap on the stirrups ,Itech stirrup bending machine adopt advanced anti twist feeding system to avoid twist of steel, make stirrup more quick and standard.Shape and bend stirrups effortlessly with our cutting-edge bending machine.

The Step-by-Step Working Process of a Pile Cage Machine

A pile cage machine is a specialized piece of equipment used to automate the production of steel reinforcement cages for deep foundation piles. This process transforms raw steel bars into a strong, cylindrical framework that provides structural integrity to concrete piles. The operation involves a precise, multi-stage workflow that combines mechanical rotation, feeding, and welding.

  1. Machine Setup and Parameter Input

The process begins with the machine setup. An operator configures the machine based on the specific project’s engineering requirements. This includes defining key parameters such as the cage diameter, length, spiral pitch (the distance between each coil of the spiral wire), and the number of longitudinal bars. These specifications are entered into the machine’s PLC (Programmable Logic Controller) control system, which will guide the entire automated production run.

  1. Loading Longitudinal Bars

The main structural framework of the pile cage is created by **longitudinal bars**, which run the entire length of the cage. In this step, these straight steel bars are loaded into the machine. The machine features holding or gripping devices to secure the bars at both ends, ensuring they are positioned correctly and aligned to form a precise circular or polygonal pattern. This secure positioning is crucial for maintaining the cage’s geometry and preventing twisting during the process.

  1. Winding the Spiral Wire

Once the longitudinal bars are secured, the machine begins to form the cage’s outer structure. A continuous length of **spiral wire** (also known as a stirrup) is fed into the machine from a decoiling unit. The machine’s rotating head or carriage then begins to wind this wire around the stationary, or slowly moving, longitudinal bars. This creates a helical, or spiral, pattern that will eventually encase the longitudinal bars and hold them in place. The spacing between each loop of the spiral is precisely controlled to meet the required design specifications.

  1. Automated Welding and Cage Formation

As the spiral wire is wound onto the longitudinal bars, the welding process occurs simultaneously. This is the most critical step where the cage’s structural integrity is determined. The machine uses an automated welding system, typically a welding electrode that rotates around the cage, to join the spiral wire to every point where it crosses a longitudinal bar. Some advanced systems even feature welding robots that adjust their position to ensure consistent, high-quality welds even on complex cage shapes like squares or rectangles. This precise and repeatable welding is a key advantage over manual fabrication methods.

  1. Output and Cage Delivery

As the welding process concludes at one end of the cage, the completed section is progressively moved out of the machine. The support heads and gripping devices guide the newly formed cage onto an unloading system, such as a loading module, which prepares it for removal. This continuous production cycle allows for the efficient manufacturing of cages in varying lengths, limited only by the machine’s design and the available workspace.
